4K 4-Port HDMI Splitter

Prijs per stuk

Inloggen

Aantal

- Repliceert een Ultra-High-Definition (UHD) digitaal audio- / videosignaal voor maximaal vier UHD HDMI-schermen
- 4K @ 60Hz resolutie, volledige 3D-video, Deep Colour en High Dynamic Range (HDR)
- Ondersteunt videoversterkerbandbreedte tot 600 MHz en 6,0 Gbps per kanaal (18 Gbps totaal) voor 4Kx2K-schermen

Kenmerken
Technische specificaties
Documentatie

4K 4-Port HDMI Splitter

Standards & Certification

HDCP 2.2/1.4
CTS 1.4b
CE
FCC
RoHS2

General

Source-to-splitter and splitter-to-display range: up to 20 m (66 ft.)
4K@60Hz 4:4:4 — total 10 meters
Max. 5 m from source to splitter
Max. 5 m from splitter to display

4K@30Hz — total 20 meters
Max. 10 m from source to splitter
Max. 10 m from splitter to display
Power adapter: 5 VDC / 2 A; 1.2 m (4 ft.)
Power consumption: 5 W

Connections
One HDMI female (input)
Four HDMI female (output)
One 5 VDC power female (input)

Signal Input/Output
Input video signal: 0.5 – 1.0 V p-p
Input DDC signal: 5 V p-p (TTL)
Maximum single-link range: 18 Gbps and 4096x2160 at 60 Hz resolution
Output video: HDMI 2.0, HDCP 2.2

Supported Video Resolutions

DTV/HDTV: 480i/480p/576i/576p/720p/1080i/1080p/4K@60Hz

Physical

LED indicators: power and port connection
On/off switch
Dimensions: 154 x 69 x 23 mm (6.1 x 2.7 x 0.9 in.)
Weight: 0.25 kg (0.7 lb.)
Housing: metal

Operating Enviroment

Operation Temperature: 0 – 40°C (32 – 104°F)
Storage Temperature: -20 – 60°C (-4 – 140°F)
Humidity (noncondensing): 0 – 96%

Package Contents

4K 4-Port HDMI Splitter
Power adapter
Quick Instruction Guide
