Chipset:
|
Qualcomm QCA7500 + QCA8334
|
|
Standards:
|
• IEEE 1901, IEEE 1905.1 and HomePlug AV Compliant
• HomePlug AV2 Compliant
• AV2 30MHz and 67MHz MIMO profi les
• AV2 30MHz and 67MHz SISO profi les
• Power Save mode
• Co- existence with HomePlug 1.0/Turbo Nodes
• Compliant to ErP 2013 directive
• IEEE 802.3 10/100/1000 Ethernet(1200Mbps)
|
|
Brutto data rate Powerline:
|
up to 1200Mbps
|
|
Frequency band:
|
2MHz to 67,5 MHz
|
|
Access-Methode Powerline:
|
Priority-based CSMA/CA channel access
|
|
Quality of Service:
|
- Priority-based CSMA/CA channel access schemes maximize effi ciency and throughput
- Integrated Quality of Service (QoS) Enhancements
- Supports IGMP managed multicast session
|
|
Modulation:
|
OFDM 4096/1024/256/64/16/8 QAM, QPSK, BPSK, ROBO, und Mini-ROBO Modulation Schema
|
|
Powerline interface:
|
Type F earthing contact connector (DE), Type C/E (FR)
|
|
Network interface:
|
1x RJ45 10/100/1000Mbit
|
|
IGMP:
|
- Support IGMP managed multicast sessions
- IGMP snooping with multicast to multiple unicast support
- IGMP/MLD Adressfiltering
|
|
Nodes/Clients:
|
max. 15 devices
|
|
Security support:
|
128bit AES Link encryption with key management
(aktivated via Simple Connect button)
|
|
LED indicators:
|
Power LED
PowerLine Link/ACT Status LED
2x Ethernet Link/ACT Status LED
|
|
Power supply:
|
Type F earthing contact connector (DE), Type C/E (FR) Switch mode 110VAC to 240VAC
|
| Power over Ethernet: |
Data PIN´s: 1,2 & 3,6
Power: 4,5 & 7,8
Max. 30 PoE IEEE802.3at 48V |
|
Operating systems:
|
all TCP/IP operating systems
|
|
Operating systems for
configurationsoftware:
|
Windows® XP32bit, Windows® Vista32/64bit, Windows®7 32/64bit
|
|
Housing:
|
synthetic housing
|
|
Environment:
|
Temperature operating: 0 ~ 40 °C
Humidity operating: 30% ~ 80% (non condensing)
Temperature storage: -25 ~ 70 °C
Humidity storage: 30% ~ 95% (non condensing)
|
|
Marks:
|
CE, RoHS
|
|
Dimensions:
|
115 x 65 x 30mm
|
|
Weight:
|
300g (only device)
|
