Camera
Beeldsensor: 1/1.8" Progressive Scan CMOS
Maximale resolutie: 3840 × 2160
Minimale verlichting:
Kleur: 0.0008 Lux @ (F1.0, AGC AAN)
Zwart/Wit: 0 Lux met IR
Sluitertijd: 1/3 s tot 1/100.000 s
Dag & Nacht: IR-cut filter
Hoekaanpassing:
Pan: 0° tot 360°
Tilt: 0° tot 90°
Rotatie: 0° tot 360°
Lens
Type lens: Vaste brandpuntsafstand, 2.8 mm en 4 mm optioneel
Brandpuntsafstand & gezichtsveld (FOV):
2.8 mm: Horizontaal 105.1°, Verticaal 54.8°, Diagonaal 128.2°
4 mm: Horizontaal 90.0°, Verticaal 45.8°, Diagonaal 109.4°
Lensbevestiging: M16
Iristype: Vast
Maximale diafragma: F1.0
Scherptediepte:
2.8 mm: 3.3 m tot ∞
4 mm: 3.8 m tot ∞
DORI (Detectie, Observatie, Herkenning, Identificatie)
2.8 mm:
Detectie: 89 m
Observatie: 35 m
Herkenning: 17 m
Identificatie: 8 m
4 mm:
Detectie: 109 m
Observatie: 43 m
Herkenning: 21 m
Identificatie: 10 m
Verlichting
Extra verlichtingstype: IR
Bereik extra verlichting: Tot 40 m
Slimme extra verlichting: Ja
IR-golflengte: 850 nm
Video
Hoofdstream:
50 Hz: 25 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 24 fps (3840 × 2160), 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
Substream:
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
Derde stream:
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
Ondersteund onder bepaalde instellingen
Videocompressie:
Hoofdstream: H.265/H.264/H.264+/H.265+
Substream: H.265/H.264/MJPEG
Derde stream: H.265/H.264
Video bit-rate: 32 Kbps - 16 Mbps
H.264 type: Baseline, Main, High Profile
H.265 type: Main Profile
Bit-rate controle: CBR, VBR
Scalable Video Coding (SVC): H.264 en H.265
Region of Interest (ROI)
1 vaste regio voor hoofdstream en substream
Audio
Audiocompressie: G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Audio bit-rate: 8 Kbps - 320 Kbps (afhankelijk van codec)
Sampling rate: 8 kHz - 48 kHz
Omgevingsruisfiltering: Ja
Netwerk
Ondersteunde protocollen: TCP/IP, HTTP/HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, enz.
Gelijktijdig live weergave: Tot 6 kanalen
API: ONVIF (Profile S, G, T), ISAPI, SDK
Gebruikers: Max. 32 gebruikers, 3 niveaus (beheerder, operator, gebruiker)
Beveiliging: Wachtwoordbeveiliging, HTTPS-encryptie, IP-filter, 802.1X-authenticatie, enz.
Opslag
Netwerkopslag: NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR)
Ondersteunde software: iVMS-4200, Hik-Connect, Hik-Central
Webbrowserondersteuning:
Met plug-in: Internet Explorer 10, 11
Zonder plug-in: Chrome 57+, Firefox 52+, Edge 89+
Beeldinstellingen
Instelbare parameters: Rotatie, verzadiging, helderheid, contrast, scherpte, witbalans
Dag/Nacht-schakeling: Dag, Nacht, Auto, Schema
Beeldverbetering: BLC, HLC, 3D DNR
SNR: ≥ 52 dB
WDR (Wide Dynamic Range): 120 dB
Privacy maskering: 4 programmeerbare polygonale maskers
Interfaces
Netwerkinterface: 1 RJ45 10M/100M zelfaanpassende Ethernetpoort
Geheugenkaartslot: MicroSD/microSDHC/microSDXC, tot 512 GB
Ingebouwde microfoon: Ja
Resetknop: Ja
Gebeurtenissen & Smart Functies
Basisevenementen: Bewegingsdetectie, videomanipulatie-alarm, uitzonderingen
Slimme gebeurtenissen: Scene-verandering detectie
Geavanceerde functies:
Gezichtsherkenning: Ja
Perimeterbeveiliging: Lijnoverschrijding, indringing, gebiedsbetreding, gebiedsverlating
Acties bij alarm: Upload naar FTP/NAS/SD-kaart, meldingen, opname starten, enz.
Algemene Specificaties
Voeding:
12 VDC ± 25%, 0.58 A, max. 7 W
PoE: IEEE 802.3af, Klasse 3, max. 8.5 W
Materiaal: Metaal
Afmetingen: Ø 74.4 mm × 179.2 mm
Gewicht: ± 525 g (pakket: ± 750 g)
Opslagcondities: -30°C tot 60°C, max. 95% luchtvochtigheid (niet-condenserend)
Taalopties: 33 talen, inclusief Nederlands
Certificeringen & Normen
EMC: CE-EMC, ICES-003, RCM
Veiligheid: CB, CE-LVD
Milieu: CE-RoHS, WEEE, Reach
Bescherming: IP67 (water-/stofdicht)
