Camera
Image Sensor 1/1.8″ Progressive Scan CMOS
Min. Illumination Color: 0.001 Lux @ (F1.2, AGC ON); B/W: 0.0003 Lux @ (F1.2, AGC ON)
Shutter Speed 1 s to 1/100,000 s
Slow Shutter Yes
P/N P/N
Wide Dynamic Range 140 dB
Day & Night IR cut filter
Power-off Memory Yes
Lens
Focus Auto, semi-auto, manual
Lens Type & FOV
2.8 to 12 mm, horizontal FOV: 107.3° to 39.8°, vertical FOV: 55.9° to 22.3°, diagonal
FOV: 130.1° to 45.7°
8 to 32 mm, horizontal FOV: 40.3° to 14.4°, vertical FOV: 22.1° to 8.2° diagonal FOV:
46.9° to 16.5°
Aperture
2.8 to 12 mm: F1.2 to 2.5
8 to 32 mm: F1.7 to F1.73
Lens Mount Integrated
Blue Glass Module Blue glass module to reduce ghost phenomenon.
P-Iris Yes
Illuminator
IR Range
2.8 to 12 mm: 30 m
8 to 32 mm: 80 m
Wavelength 850 nm
Smart Supplement Light Yes
Video
Max. Resolution 1920 × 1080
Main Stream
50Hz: 50fps (1920 × 1080, 1280 × 720)
60Hz: 60fps (1920 × 1080, 1280 × 720)
Sub-Stream
50Hz: 25fps (704 × 576, 640 × 480)
60Hz: 30fps (704 × 480, 640 × 480)
Third Stream
50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Fourth Stream
50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Fifth Stream
50Hz: 25fps (704 × 576, 640 × 480)
60Hz: 30fps (704 × 480, 640 × 480)
Custom Stream
50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Video Compression
Main stream: H.265+/H.265/H.264+/ H.264
Sub-stream/Third stream/Fourth stream/Fifth stream/custom
stream:H.265/H.264/MJPEG
Video Bit Rate 32 Kbps to 16 Mbps
H.264 Type Baseline Profile/Main Profile/High Profile
H.265 Type Main Profile
H.264+ Main Stream supports
H.265+ Main Stream supports
Bit Rate Control CBR/VBR
Stream Type Main stream/Sub-stream/third stream/fourth stream/fifth stream/custom stream
Scalable Video Coding (SVC) H.265 and H.264 support
Region of Interest (ROI) 4 fixed regions for each stream
Audio
Environment Noise Filtering Yes
Audio Sampling Rate 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Audio Compression G.711/G.722.1/G.726/MP2L2/PCM/MP3
Audio Bit Rate
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/32Kbps(PCM)/8-
320Kbps(MP3)
Audio Type Mono sound
Network
Simultaneous Live View Up to 20 channels
API ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, ISUP
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, SRTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP,
PPPoE, NTP,UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
Smooth Streaming Yes
User/Host Up to 32 users. 3 user levels: administrator, operator and user
Security
Password protection, complicated password, HTTPS encryption,802.1X authentication
(EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest
authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, RTP/RTSP
OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2
Network Storage
microSD/SDHC/SDXC card (256 GB) local storage, and NAS (NFS, SMB/CIFS), auto
network replenishment (ANR)
Together with high-end Hikvision memory card, memory card encryption and health
detection are supported.
Client iVMS-4200, Hik-Connect, Hik-Central
Web Browser
Plug-in required live view: IE8+
Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+
Local service: Chrome 41.0+, Firefox 30.0+
Smart IR
The IR LEDs on camera should support Smart IR function to automatically adjust power
to avoid image overexposure.
Day/Night Switch Day, Night, Auto, Schedule, Triggered by Alarm In
Target Cropping Yes
Picture Overlay LOGO picture can be overlaid on video with 128 × 128 24bit bmp format
Image Enhancement BLC, HLC, 3D DNR, Defog, EIS, Distortion Correction
Image Parameters Switch Yes
Image Settings
Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance
adjustable by client software or web browser
SNR ≥52dB
Interface
Alarm 2 input, 2 outputs (max. 24 VDC, 1 A)
Audio
-IZHSY:
1 input (line in), 3.5 mm connector, max. input amplitude: 3.3 vpp, input impedance:
4.7 KΩ, interface type: non-equilibrium; 1 output (line out), 3.5 mm connector, max.
output amplitude: 3.3 vpp, output impedance: 100 Ω, interface type: non-equilibrium,
mono sound
RS-485 With -Y: 1 RS-485(half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
Video Output 1 Vp-p Composite Output(75Ω/CVBS)(For debugging only)
On-board Storage Built-in micro SD/SDHC/SDXC slot, up to 256 GB
Hardware Reset Yes
Communication Interface 1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port
Power Output With -Y: 12 VDC, max. 200 mA (supported by all power supply types)
Heater Yes
Smart Feature-Set
Basic Event
Motion detection, video tampering alarm, vibration detection, exception (network
disconnected, IP address conflict, illegal login, HDD full, HDD error)
Smart Event
Line crossing detection, up to 4 lines configurable
Intrusion detection, up to 4 regions configurable
Region entrance detection, up to 4 regions configurable
Region exiting detection, up to 4 regions configurable
Unattended baggage detection, up to 4 regions configurable
Object removal detection, up to 4 regions configurable
Scene change detection, audio exception detection, defocus detection
Counting Yes
Intelligent (Deep Learning Algorithm)
Face Recognition
Detects up to 30 faces simultaneously;
Supports swing left and right from -60° to 60°, tilt up and down from -30° to 30°;
Up to 3 face libraries with up to 30000 faces each are configurable;
Recognizes face identity via face modeling, grading and comparing to those in face
library;
Supports face library encryption.
Multi-target-type Detection
Supports simultaneous detection of human body and face
Gets 8 face features and 13 human body features
Face Counting
Supports entering/exiting counting (track 30 targets simultaneously);
Supports facial recognition;
Supports 24-hour dynamic deduplication and face library deduplication (up to 3 face
libraries with up to 30000 faces);
Supports reporting alarms when detecting the face is the same as that in the face
library.
Hard Hat Detection
Detects up to 30 human targets simultaneously
Supports up to 4 shield regions
Queue Management
Detects queuing-up people number, and waiting time of each person
Generates reports to compare the efficiency of different queuing-ups and display the
changing status of one queue
Supports raw data export for further analysis
Premier Protection
Line crossing, intrusion, region entrance, region exiting
Support alarm triggering by specified target types (human and vehicle)
Filtering out mistaken alarm caused by target types such as leaf, light, animal, and flag,
etc.
General
Linkage Method
Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm
output, trigger recording, trigger capture
Trigger recording: memory card, network storage, pre-record and post-record
Trigger captured pictures uploading: FTP, SFTP, HTTP, NAS, Email
Trigger notification: HTTP, ISAPI, alarm output, Email
Online Upgrade Yes
Dual Backup Yes
Firmware Version V5.5.121
Web Client Language
33 languages
English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak,
French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian,
Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai,
Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil),Ukrainian
General Function
Anti- flicker, 5 streams and up to 5 custom streams, EPTZ, heartbeat, mirror, privacy
masks, flash log, password reset via e-mail, pixel counter
Software Reset Yes
Storage Conditions -40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup and Operating Conditions
-40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing)
Power Supply
12 VDC ± 20%, three-core terminal block, reverse polarity protection; PoE:802.3at,
Type 2 Class 4
Power Consumption and Current
12 VDC, 1.33 A, max. 16.0 W
PoE: (802.3at, 42.5V-57V), 0.43 A to 0.31 A, max. 18.0 W
Power Interface 3-core terminal block
Camera Material Aluminum alloy body
Screw Material Mild steel
Camera Dimension
Without -Y: Ø144 × 347 mm (Ø5.7″ × 13.7″)
With -Y: Ø140 × 351 mm (Ø5.5″ × 13.8″)
Package Dimension 405 × 190 × 180 mm (15.9″ × 7.5″ × 7.1″)
Camera Weight 1920 g (4.2 lb.)
With Package Weight 3060 g (6.7 lb.)
Metadata
Metadata
Metadata of intrusion detection, line crossing detection, region entrance detection,
region exiting detection, unattended baggage detection, object removal, face capture
and queue management are supported.
Approval
Class Class B
EMC
FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN
61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC
(ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)
Safety
UL (UL 60950-1); CB (IEC 60950-1: 2005 + Am 1:2009 + Am 2: 2013); CE-LVD (EN
60950-1: 2005 + Am 1: 2009 + Am 2:2013); BIS (IS 13252(Part 1): 2010+A1: 2013+A2:
2015); LOA (IEC/EN 60950-1)
Environment CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Protection Ingress protection: IK10 (IEC 62262:2002), IP67 (IEC 60529-2013)
Automotive and Railway With -R: EN50121-4
Anti-Corrosion Protection
With -Y: NEMA 4X(NEMA 250-2014). Anti-corrosion coating, not recommended in high
salinity/humidity/acidity environment
Other With -Y: PVC FREE
