Beeldsensor
1/1.8" Progressive Scan CMOS
Maximale resolutie
2688 × 1520
Minimale verlichting
Kleur: 0,0005 Lux @ (F1.2, AGC AAN)
Z/W: 0,0001 Lux @ (F1.2, AGC AAN); Z/W: 0 Lux met IR
Sluitertijd
1s tot 1/100.000 s
Dag & Nacht
IR-cut filter, blauwglazen module (minder ghosting)
Hoekaanpassing
Pan: 0° tot 355°, Tilt: 0° tot 85°, Rotatie: 0° tot 355°
Type lens
Motorzoom varifocale lens, 2.8 tot 12 mm
Brandpuntsafstand & Gezichtsveld (FOV):
2.8–12 mm: Horizontaal 114,6°–41,8°, Verticaal 59,3°–23,6°, Diagonaal 141,3°–48,1°
Focus
Auto, Semi-auto, Handmatig
Iris-type
P-iris 2.8–12 mm: F1.47 tot F2.53
DORI (Detectie, Observatie, Herkenning, Identificatie)
Detectie: 151,7 m
Observatie: 60,2 m
Herkenning: 30,3 m
Identificatie: 15,2 m
Type aanvullend licht
IR, Witte LED
Bereik aanvullend licht:
2.8–12 mm: 40 m
Slim aanvullend licht
Ja
IR-golflengte
850 nm
Video Hoofdstream (Monitoringmodus):
50 Hz: tot 50 fps (2688 × 1520, 1280 × 720), tot 100 fps (1920 × 1080)
60 Hz: tot 60 fps (2688 × 1520, 1280 × 720), tot 120 fps (1920 × 1080)
Hoofdstream (Slimme modus):
50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
Substream:
50 Hz: 25 fps (1280 × 720, 704 × 576, 640 × 480)
60 Hz: 30 fps (1280 × 720, 704 × 480, 640 × 480)
Derde stream:
50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Vierde stream:
50 Hz: 25 fps (704 × 576, 640 × 480)
60 Hz: 30 fps (704 × 480, 640 × 480)
Vijfde stream:
50 Hz: 25 fps (704 × 576, 640 × 480)
60 Hz: 30 fps (704 × 480, 640 × 480)
Videocompressie
Hoofdstream: H.265+/H.265/H.264+/H.264
Substream: H.265/H.264/MJPEG
Derde stream: H.265/H.264
Vierde stream: H.265/H.264/MJPEG
Vijfde stream: H.265/H.264/MJPEG
Videobitsnelheid
32 Kbps tot 8 Mbps
H.264-type
Baselineprofiel, Mainprofiel, Hoogprofiel
H.265-type
Mainprofiel
Bitsnelheidsregeling
CBR, VBR
Schaalbare videocodering (SVC)
H.264 en H.265
Regio van interesse (ROI)
4 vaste regio's per stream
Doeluitsnijding
Ja
Audiotype
Mono
Audiocompressie
G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Audiobitsnelheid:
64 Kbps (G.711ulaw/G.711alaw)
16 Kbps (G.722.1)
16 Kbps (G.726)
32 tot 192 Kbps (MP2L2)
8 tot 320 Kbps (MP3)
16 tot 64 Kbps (AAC-LC)
Audiosamplingfrequentie
8 kHz/16 kHz/32 kHz/48 kHz
Omgevingsruisonderdrukking
Ja
Netwerk
Ondersteunde protocollen
TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, DHCP, DNS, DDNS, SRTP, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, ARP, WebSocket, WebSockets
Gelijktijdige live-weergave
Maximaal 20 kanalen
API
ISAPI, SDK, ISUP, OTAP, ONVIF (Profiel S, Profiel G, Profiel T, Profiel M)
Gebruikers/hosts
Maximaal 32 gebruikers; 3 gebruikersniveaus: beheerder, operator en gebruiker
Beveiliging
Wachtwoordbeveiliging, complexe wachtwoorden, HTTPS-encryptie, 802.1X-authenticatie (EAP-TLS, EAP-LEAP, EAP-MD5), watermerk, IP-adresfilter, basis- en digest-authenticatie voor HTTP/HTTPS, WSSE en digest-authenticatie voor Open Network Video Interface, RTP/RTSP via HTTPS, instellingen voor time-outbeheer, beveiligingsauditlog, TLS 1.2, TLS 1.3, TPM 2.0 (FIPS 140-2 niveau 2), AES128/256
Netwerkopslag
NAS (NFS, SMB/CIFS), Automatische netwerkaanvulling (ANR), ondersteuning voor geheugenkaarten van Hikvision met encryptie en gezondheidsdetectie
Client
iVMS-4200, Hik-Connect, Hik-Central
Plug-in vereist voor live-weergave
IE 10, IE 11
Plug-in vrije live-weergave
Chrome 57.0+, Firefox 52.0+, Edge 89+, Safari 11+
