- Main Stream
50 Hz: 25 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720)
- Sub-Stream
50 Hz: 25 fps (704 × 576, 640 × 480)
60 Hz: 30 fps (704 × 480, 640 × 480)
- Third Stream
50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
- Fourth Stream
50 Hz: 25 fps (704 × 576, 640 × 480)
60 Hz: 30 fps (704 × 480, 640 × 480)
- Fifth Stream
50 Hz: 25 fps (704 × 576, 640 × 480)
60 Hz: 30 fps (704 × 480, 640 × 480)
- Video Compression
Main stream: H.265+/H.265/H.264+/H.264,
Sub-stream: H.265/H.264/MJPEG,
Third stream: H.265/H.264,
Fourth stream: H.265/H.264/MJPEG,
Fifth stream: H.265/H.264/MJPEG
- Video Bit Rate32 Kbps to 8 Mbps
- H.264 TypeBaseline Profile,Main Profile,High Profile
- H.265 TypeMain Profile
- Bit Rate ControlCBR,VBR
- Scalable Video Coding (SVC)H.264 and H.265 encoding
- Target CroppingYes
- Region Of Interest (ROI)4 fixed regions for each stream
- Face Capture
Detects up to 60 faces simultaneously,
Supports swing left and right from -60° to 60°, tilt up and down from -30° to 30°,
Uploads face with background and closed-up face pictures
- People Counting
Supports crossline people counting,
Supports counting, displaying and exporting the people flow data of entering and exiting. (The data is stored in the flash.),
The real-time people flow data is displayed on the screen. ,
Supports swing left and right from -60° to 60°, tilt up and down from -30° to 30°.,
Uploads face with background and closed-up face picture.,
Supports real-time uploading and uploading by statistic cycle
- Queue Management
Supports up to 8 detection regions, and independent arming schedule and linkage method,
Supports 2 detection modes: regional people queuing-up, waiting time detection,
Generates reports to compare the efficiency of different queuing-ups and display the changing status of one queue,
Supports raw data export for further analysis,
Supports real-time data uploading and scheduled data uploading,
Regional people queuing-up: supports 4 alarm trigger conditions, including greater than threshold, less than threshold, equal to threshold, not equal to threshold,
Waiting time detection: supports 1 alarm trigger condition, including greater than threshold
- Heat Map
A graphic description of visits (by calculating amount of people or amount of dwell time) in a configured area.,
Two report types are available, space heat map and time heat map line chart.
- Perimeter Protection
Line crossing, intrusion, region entrance, region exiting,
Support alarm triggering by specified target types (human and vehicle)
- MetadataIntrusion detection,line crossing detection,region entrance detection,region exiting detection
- On/Off Duty Detection
Supports up to 8 detection regions, and independent arming schedule and linkage method,
Supports 2 detection modes: absence detection, on/off duty detection,
Supports parameter settings: person on duty, absence duration
- Power
12 VDC ± 20%, 0.85A, max. 10.2 W,
PoE: IEEE 802.3af, Type 1, Class 3, 36 V to 57 V, 0.3 A to 0.17 A, max. 10.2 W
- MaterialAluminum alloy body
- Dimension
Ø97.6 mm × 121.5 mm (Ø3.85 × 4.79\")"
- Package Dimension150 mm × 150 mm × 141 mm (6.0" × 6.0" × 5.6")
- WeightApprox. 620 g (1.37 lb.)
- With Package WeightApprox. 805 g (1.78 lb.)
- Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Startup And Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Language
33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
- General FunctionHeartbeat,anti-banding,one-key reset,mirror,password protection,flash log
- DemistYes
