Camera Module
One-touch Link Yes
Tracking Mode Manual/ Auto
Multiple Targets Tracking Yes
Number of Targets Up to 30 targets can be detected at the same time.
Target Switch Time <1 s
Calibration Manual/ Auto
Tracking Duration Up to 60 s
Sensitivity Settings Yes
Smart Image Enhancement HLC, BLC, 3D DNR, Regional Exposure
Panoramic Camera
Image Sensor 1/1.8" progressive scan CMOS
Min. Illumination
Color: 0.0005 Lux @(F1.6, AGC ON)
B/W: 0.0001 Lux @(F1.6, AGC ON)
Focal Length 2.8 mm
Privacy Mask 8 programmable polygon privacy masks, mask color configurable
3D DNR Yes
HLC Yes
Field of View
Horizontal field of view: 180°
Vertical field of view: 85°
Main Stream Resolution
50Hz: 25fps (5520 × 2400, 4096 × 1800, 3840 × 1680, 2784 × 1200)
60Hz: 30fps (5520 × 2400, 4096 × 1800, 3840 × 1680, 2784 × 1200)
Sub-Stream Resolution
50Hz: 25fps (2048 × 896, 1280 × 560, 704 × 320)
60Hz: 30fps (2048 × 896, 1280 × 560, 704 × 320)
Third Stream Resolution
50Hz: 25fps (4096 × 1800, 3840 × 1680, 2784 × 1200, 2048 × 896, 1280 × 560, 704 ×
320)
60Hz: 30fps (4096 × 1800, 3840 × 1680, 2784 × 1200, 2048 × 896, 1280 × 560, 704 ×
320)
Tracking PTZ Camera
Image Sensor 1/1.8" progressive scan CMOS
Min. Illumination
Color: 0.0005 Lux @(F1.2, AGC ON)
B/W: 0.0001 Lux @(F1.2, AGC ON)
0 Lux with IR
SNR ≥52dB
Shutter Speed 1 s to 1/30,000 s
Slow Shutter Yes
Focal Length 6.0 to 240 mm
Zoom Speed Approx. 4.4 s
FOV
Horizontal field of view: 56.6° to 1.8° (Wide-Tele)
Vertical field of view: 33.7° to 1.0° (Wide-Tele)
Diagonal field of view: 63.4° to 2.0° (Wide-Tele)Aperture F1.2 to F4.5
Digital Zoom 16 ×
Optical Zoom 40 ×
WDR 120 dB
EIS Yes
Optical Defog Yes
Regional Focus Yes
Pan and Tilt Range Pan: 360° endless, Tilt: -15° to 90° (Auto Flip)
Pan and Tilt Speed
Pan Manual Speed: 0.1°/s to 210°/s (Configurable), Pan Preset Speed: 240°/s
Tilt Manual Speed: 0.1°/s to 150°/s (Configurable), Tilt Preset Speed: 200°/s
Proportional Zoom Yes
Preset 300
Patrol Scan 8 patrols
Pattern Scan 4 patterns
Park Action
Preset/ Pattern Scan/ Patrol Scan/ Auto Scan/ Tilt Scan/ Random Scan/ Frame Scan/
Panorama Scan
Scheduled Task
Preset/ Pattern Scan/ Patrol Scan/ Auto Scan/ Tilt Scan/ Random Scan/ Frame Scan/
Panorama Scan/ Dome Reboot/ Dome Adjust/ Aux Output
Privacy Mask 24 programmable polygon privacy masks, mask color configurable
Power-off Memory Yes
3D Positioning Yes
PTZ Status Display Yes
Preset Freezing Yes
Main Stream Resolution
50Hz: 25fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)
60Hz: 30fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)
Sub-Stream Resolution
50Hz: 25fps (704 × 576, 640 × 480, 352 × 288)
60Hz: 30fps (704 × 480, 640 × 480, 352 × 240)
Third Stream Resolution
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
Illuminator
IR Distance 250 m
Smart IR Yes
Video
H.264 Type Baseline Profile/Main Profile/High Profile
Video Compression
Main Stream: H.265/H.264
Sub-Stream: H.265/H.264/MJPEG
Third Stream: H.265/H.264
H.264+ Yes
H.265+ Yes
Audio
Audio Compression G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM
Audio Sampling Rate MP2L2: 16kHz, 32kHz, 44.1kHz, 48kHz, PCM: 8kHz, 16kHz, 32kHz, 44.1kHz, 48kHzSmart Features
Smart Event
[Panoramic Channel]
Intrusion detection, line crossing detection, region entrance detection, region exiting
detection
[PTZ Channel]
Intrusion detection, line crossing detection, region entrance detection, region exiting
detection, unattended baggage detection, object removal detection
Smart Tracking
Manual Tracking; Panoramic Tracking; Event Tracking; support patrol tracking in
multiple scenes
Alarm Linkage
Preset, patrol scan, pattern scan, memory card video recording, alarm output, sending
email, notify surveillance center, upload to FTP
Smart Encoding H.265+, H.264+, ROI, SVC
Network
Network Storage NAS (NFS, SMB/CIFS)
Protocols
TCP/IP, IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS,
NTP, RTSP, RTCP, RTP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
API
Open-ended API, ONVIF (Profile S, Profile G), ISAPI, Hikvision SDK, Third-party
management platform, ISUP
Simultaneous Live View 20
User/Host 32
Smooth Streaming Yes
Security Measures
Authenticated username and password, MAC address binding, HTTPS encryption,
802.1X authenticated access, IP address filter
Client iVMS-4200
Web Browser IE 8+
Interface
Communication Interface RJ45,Self-adaptive 10 M/100 M/1000 M Ethernet Interface
Fiber Interface
FC interface, built-in fiber module, 1000M, TX1310/RX1550 nm wavelength, single
module fiber, up to 20 km transmission distance
On-board Storage Built-in microSD slot, support microSD/microSDHC/microSDXC cards, up to 256 GB
RS-485 Half duplex, HIKVISION, Pelco-P and Pelco-D self-adaptive
Alarm Input 7-ch alarm input
Alarm Output 2-ch alarm output
Audio Input 1 audio input, 2.0 to 2.4Vp-p, 1k Ohm±10%
Audio Output 1 audio output, line level, impedance: 600 Ω
General
Power 36 VDC
Working Temperature -40°C to 70°C (-40°F to 158°F)
Working Humidity ≤ 95%
Protection
IP66 Standard, IK10, 6000V Lightning Protection, Surge Protection and Voltage
Transient Protection
Reset Yes
Demist Yes
Material ADC12
Dimensions Φ 391.8mm × 400.5mm (Φ 15.43"×15.77")
Weight Approx. 18 kg (39.68 lb)
