Thermische Module
Beeldsensor
Vanadiumoxide, ongekoeld brandvlak
Resolutie
384 × 288 (uitgangsbeeld: 1280 × 720)
Pixelafstand
12 μm
Golflengtebereik
8 μm tot 14 μm
NETD
< 35 mK (@25 °C, F#=1.0)
Brandpuntsafstand
4mm
Focusmodus
Athermalisch
IFOV
3,00 mrad
Diafragma
F1.0
Gezichtsveld
60.2° × 40.5° (H × V)
Minimale scherpstelafstand
0,6 m
Digitale zoom
×2, ×4, ×8
Optische Module
Beeldsensor
1/2.8" Progressive Scan CMOS
Resolutie
2688 × 1520 (4 MP)
Minimale verlichting
Kleur: 0,05 Lux, Z/W: 0,01 Lux (F1.2, AGC AAN)
Gezichtsveld
58.8° × 34.4° tot 2.18° × 1.2°
Brandpuntsafstand
4.8 - 153 mm, 32× zoom
Diafragma
F1.2 - F4.4
Focusmodus
Auto/Semi-auto/Handmatig
Sluitertijd
1s tot 1/100.000s
WDR
120 dB
Optisch defog
Niet fysiek, softwarematig ondersteund
Beeldweergave
Beeld-in-beeld
Thermisch beeld op optisch scherm
Doelkleuring
Ondersteund (wit heet / zwart heet)
PTZ (Pan, Tilt, Zoom)
Bewegingsbereik
Pan 360° continu, Tilt -5° tot +90°
Pansnelheid
0.1°/s tot 200°/s, Preset: 240°/s
Tiltsnelheid
0.1°/s tot 105°/s, Preset: 200°/s
Proportionele zoom
Ja
Presets
300 totaal, 273 configureerbaar
Patrolscan
8, tot 32 presets per scan
Patroonscan
4, >10 minuten per patroon
Geheugen bij stroomuitval
Ja
Parkactie
Preset, patroon, scan, etc.
Geplande taken
Diverse acties, inclusief herstart
Verlichting
IR-bereik
Tot 100m
IR-intensiteit en hoek
Automatisch aangepast
Slimme Functies
VCA (Video Content Analyse)
4 regels (lijnoverschrijding, indringing, etc.), tot 10 scènes, 8 regels per scène
Temperatuurmeting
3 soorten regels, tot 21 per scène
Temperatuurbereik
-20°C tot 150°C
Nauwkeurigheid
±8°C
Branddetectie
Dynamisch, tot 10 brandpunten
Video en Audio
Hoofdstream (optisch):
50 Hz: 25 fps bij 2688×1520, 1920×1080, etc.
60 Hz: 30 fps
Hoofdstream (thermisch):
25 fps bij 1280×720, 704×576, etc.
Substream (optisch/thermisch):
25/30 fps bij lagere resoluties
Videocompressie
H.265+/H.265/H.264+/H.264/MJPEG
Audiocompressie
G.711u/a, G.722.1, MP2L2, G.726, PCM
Netwerk
Protocollen
IPv4/6, HTTP(S), RTSP, FTP, NTP, SNMP, enz.
Opslag
microSD (tot 256GB), NAS, ANR
API
ISAPI, SDK, ONVIF (S, G, T)
Liveweergave
Tot 20 kanalen
Gebruikers
Max. 32 gebruikers, 3 niveaus
Beveiliging
Wachtwoord, HTTPS, MAC-binding, IP-filter
Software
Client
iVMS-4200, Hik-Connect
Browserondersteuning
IE11 (met plug-in), Chrome/Firefox (zonder plug-in)
Aansluitingen
Alarm
7 ingangen, 2 uitgangen
Audio in/out
Lijn/MIC in, lijn uit
Netwerk
RJ45 Ethernet, RS-485
Video-uitgang
Analoog 1.0 V [p-p] / 75 Ω
Algemeen
Taal
32 talen incl. Nederlands
Voeding
24VAC / 36VDC / 48VDC ±20%, tweepolige klem
Hi-PoE
Verbruik: Max. 30 W
Temperatuur/Vochtigheid
-40°C tot 70°C, ≤90%
Bescherming
IP66, overspanningsbeveiliging (TVS 6000V)
Afmetingen
305 × 185 × 163 mm
Gewicht
Ca. 3.9 kg
Detectieafstand
VCA detectie mensen
40m
VCA detectie voertuigen
120m
