Thermal Module
Image Sensor Vanadium Oxide Uncooled Focal Plane Arrays
Resolution 160 × 120 (the resolution of output image is 320 × 240)
Pixel Interval 17 μm
Response Waveband 8 μm to 14 μm
NETD (Noise Equivalent
Temperature Difference)
≤ 40 mK (25 °C, F# = 1.1)
Focal Length 6.2 mm
IFOV 2.74 mrad
Field of View 25° × 18.7° (H × V)
Min. Focusing Distance 0.6 m
Aperture F 1.1
Digital Zoom ×2, ×4, ×8
Image Effect
Target Coloration Yes. Supported in white hot and black hot mode.
Audible and Visual Alarm
White Light Range Up to 40 m
Visual Alarm Yes. White light used as the visual alarm, flashing frequency adjustable
Audio alarm Yes. 6 audio alarms are supported to cover all kinds of alarm.
Smart Function
VCA (Video Content Analysis)
4 VCA rule types (line crossing, intrusion, region entrance, and region exiting), up to 8
VCA rules in total.
Temperature Measurement
3 temperature measurement rule types, 21 rules in total (10 points, 10 areas, and 1
line).
Temperature Range -20 °C to 150 °C (-4 °F to 302 °F)
Temperature Accuracy ± 8 °C (14.4 °F)
Fire Detection Dynamic fire detection, up to 10 fire points detectable.
Video & Audio
Main Stream 25 fps (1280 × 720 ,704 × 576 ,640 × 480 ,352 × 288 ,320 × 240)
Sub-stream 25 fps (704 × 576 ,352 × 288 ,320 × 240)
Third Stream 25 fps (1280 × 720 ,704 × 576 ,352 × 288 ,320 × 240)
Video Compression
Main Stream: H.265/H.264
Sub-Stream: H.265/H.264/MJPEG
Third Stream: H.265/H.264/MJPEG
Audio Compression G.711u/G.711a/G.722.1/MP2L2/G.726/PCM
Network
Protocols
IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP,
RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE
Network Storage
MicroSD/SDHC/SDXC card (up to 256 G) local storage, and NAS (NFS, SMB/CIFS), auto
network replenishment (ANR)
API
Open-ended API, supporting ISAPI, HIKVISION SDK, and third-party management
platform, open network video interface
Simultaneous Live View Up to 20 channels
User/Host Level Up to 32 users, 3 levels: Administrator, Operator, User
Security
User authentication (ID and PW), MAC address binding, HTTPS encryption, IEEE
802.1x(EAP-MD5, EAP-TLS), access control, IP address filtering
Client iVMS-4200, Hik-Connect
Web Browser IE 11, Chrome 41-44, Firefox 30-51
Interface
Alarm Input 1-ch input (0-5 VDC)
Alarm Output 1-ch relay output, alarm response actions configurable
Alarm Action
SD card record/relay output/smart capture/FTP upload/email linkage/ audio
alarm/white light alarm
Audio Input
1, 3.5 mm Mic in/Line in interface.
Line input: 2-2.4 V [p-p], output impedance: 1 KΩ ± 10%
Audio Output Linear level, impedance: 600 Ω
Communication Interface 1, RJ45 10 M/100 M self-adaptive Ethernet interface.
General
Menu Language
32 languages
English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak,
French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian,
Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai,
Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
Power 12 VDC± 25%, two-core terminal block
PoE (802.3af, class 3)
Power Consumption
9 VDC to 15 VDC:0.4A, max. 4.5 W
PoE (802.3af, class 3): 42.5 V to 57 V, 0.14 A to 0.22 A, max. 5.0 W
Working Temperature/Humidity
-40 °C to 65 °C (-40 °F to 149 °F)
95% or less
Protection Level
IP66 Standard
TVS 6000V lightning protection, surge protection, voltage transient protection
Dimensions 354 mm × 144.1 mm × 156.7 mm (13.94" × 5.67" × 6.17")
Weight Approx. 1.71 kg (3.77 lb)
