Beeldsensor
Vanadiumoxide ongekoelde focal plane array
Resolutie
160 × 120 pixels
Pixelafstand
12 μm
Spectraal bereik
8 μm tot 14 μm
NETD (Noise Equivalent Temperature Difference)
<50 mK (bij 25°C, F#=1.1)
Brandpuntsafstand
1.3 mm
Gezichtsveld (FOV)
90.0° (horizontaal) × 65.2° (verticaal)
Minimale scherpstelafstand
0,01 m
Diafragma
F1.0
Video en Audio
Hoofdstream (thermisch): 25 fps (1280 × 720, 704 × 576, 640 × 480, 352 × 288, 320 × 240)
Substream (thermisch): 25 fps (704 × 576, 352 × 288, 320 × 240)
Videocompressie
H.264 / H.265 / MJPEG
H.265/MJPEG ondersteunt Main Profile
H.264 ondersteunt Baseline/Main/High Profile
Netwerkprotocollen
IPv4, HTTP, HTTPS, QoS, FTP, SNMP, DDNS, TCP, PPPoE, RTSP, UPnP
Netwerkopslag
MicroSD/SDHC/SDXC-kaart (tot 256 GB) lokale opslag
API-ondersteuning
ISAPI, HIKVISION SDK, platforms van derden
Open Network Video Interface (ONVIF)
Profielen S en G
Live weergave & Gebruikersbeheer
Gelijktijdige live weergave: Maximaal 20 kanalen
Gebruikers/hosts
Tot 32 gebruikers
3 niveaus: Beheerder, Operator, Gebruiker
Beveiliging
Gebruikersauthenticatie (ID en wachtwoord)
MAC-adresbinding
HTTPS-versleuteling
IEEE 802.1x (EAP-MD5, EAP-TLS)
Toegangscontrole
IP-adresfiltering
Clients
iVMS-4200 / EZVIZ / HIK-CONNECT / HIK-CENTRAL
Webbrowser-ondersteuning
Internet Explorer 11+, Chrome 18.0+, Firefox 5.0+, Safari 5.02+
Interfaces
Alarmuitgang: 1, configureerbare alarmactie
Alarmacties
SD-opname / relaisuitgang / slimme opname / FTP-upload
Audio-invoer
Ingebouwde microfoon
Audio-uitvoer
Ingebouwde luidspreker
Communicatie-interface
1 RS-485-interface (half-duplex)
Resetknop
1, ingebouwd op het moederbord
Radar
Werkfrequentie
60 GHz ~ 64 GHz
Modulatiegolfvorm
FMCW
Detectieafstand
0,3 m - 4 m
Taalondersteuning Webclient
Ondersteunt 32 talen, waaronder: Engels, Russisch, Estisch, Bulgaars, Hongaars, Grieks, Duits, Italiaans, Tsjechisch, Slowaaks, Frans, Pools, Nederlands, Portugees, Spaans, Roemeens, Deens, Zweeds, Noors, Fins, Kroatisch, Sloveens, Servisch, Turks, Koreaans, Traditioneel Chinees, Thais, Vietnamees, Japans, Lets, Litouws, Portugees (Brazilië)
Algemeen
Voeding:
DC 12 V (±20%): 0.5 A, max. 5W
PoE (802.3af): 36 V tot 57 V, 0.17 A tot 0.11 A, max. 6W
Werktemperatuur/-vochtigheid:
Temperatuur: -20°C tot 50°C
Vochtigheid
≤95%
Beschermingsgraad
IP40
Afmetingen
130 mm × 102 mm × 75 mm
Gewicht
0,38 kg
Montage
Hoekmontage
Certificaat
EMC EN55032
