Hikvision netwerk speaker plafond model
Speaker
- Rated Power6 W
- Impedance8 Ω
- Max. Acoustic Pressure100 dBSPL
- Sensitivity(1 M, 1 W)93 dB
- DirectionAll directions
- Frequency Response300 Hz to 15 kHz
- SNR82 dB
- Function
- Audio AlgorithmAEC?AGC?ANS?DRC
- Audio Bit RateG.711ulaw(64 Kbps)/G.711alaw(64 Kbps)/MP3(128 Kbps)
- Audio File FormatMP3, WAV
- NTP TimingSupport
- BroadcastRegular broadcast, live broadcast, emergency broadcast
- Speech SynthesisEnglish
Network
- Network ProtocolIPv4, HTTP, HTTPS , SIP, SSL/TLS , DNS, NTP, TCP, UDP, IGMP, ICMP, DHCP, ARP, SSH
- Interface Protocol (API)ISAPI, ISUP, SIP, RTP
Functions
- Audio FunctionSupport digital noise reduction, manually adjustable for 5 gears to ensure communication/audio quality.
Communication
- Communication MethodSupport wired network and bluetoothcommunication
Interface
- Ethernet InterfaceRJ45 10 M/100 M Adaptive Ethernet port × 1
- Local StorageBuilt-in 4 GB EMMC (Audio file storage is 1 GB.)
- APIISAPI, ISUP, SIP
- AlarmAlarm input × 2
- Audio In3.5 mm audio interface × 1
- Audio Out
fixed resistance output × 1,phoenix terminal,8 Ω
*The primary speaker(6 W, 8 Ω) can be connected to a maximum of 1 secondary speaker(6 W, 8 Ω).
General
Approval
- RF
CE-RED:EN 301489-1 V2.2.3 (BT or 2.4G),EN 301489-17 V3.2.4 (BT or 2.4G),EN 300 328 V2.2.2 (BT or 2.4G) ,EN62311 2020(BT or 2.4G)
RCM: EN 300 328 V2.2.2 (BT or 2.4G) ,AS/NZS 2772.2:2016+A1:2018, ARPANSA RPS S-1 Radiation Protection Series S-1 (Rev.1), ARPANSA RPS S01 Advisory Note
IC ID: RSS-247(BT or 2.4G)
ANATEL: Resolution No. 680/2017,Act No. 14448/2017,Act No. 950/2018,Act No. 1120/2018
- EMCCE-EMC: EN 55032:2015+A11:2020+A1:2020, EN IEC 61000-3-2:2019, EN 61000-3-3:2013+A1:2019+A2:2021, EN 55035:2017+A11:2020 RCM: AS/NZS CISPR 32: 2015 IC: ICES-003: Issue 7
- Safety
CB: IEC 62368-1:2014
CE-LVD: EN 62368-1:2014/A11:2017
- Environment
CE-RoHS: 2011/65/EU
WEEE: 2012/19/EU
Reach: Regulation (EC) No 1907/2006
