Video/Audio Input
IP video input: 128-ch
Two-way audio input: 1-ch, RCA (2.0 Vp-p, 1kΩ)
Network
Remote connection: 256
Video/Audio Output
Audio Output: 1-ch, RCA (2.0Vp-p, 1KΩ)
VGA Output: 1-ch, resolution: 1920*1080P/60Hz, 1600*1200/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz
Hard Disk
eSATA: 1 eSATA interface
SATA: 16 SATA interfaces for 16 HDDs miniSAS
(Optional): 2 miniSAS interface Disk array
Number of array: 8 External Interface
Optic fiber interface: 4 1000 Mbps optional optic fiber interfaces
Network Interface: 4 RJ-45 10 /100 /1000 Mbps self-adaptive Ethernet interfaces
Serial Interface: RS-232, RS-485, Keyboard USB
Interface
Front panel: 2 × USB 2.0
Rear panel: 2 × USB 3.0
Alarm In: 16-ch
Alarm Out: 4-ch
General
Power Supply: 100-240 VAC, 550W Consumption
(without hard disk and POE): ≤ 140W
Working Humidity: 10% ~ 90%
Dimensions: 442 × 494 146 mm (17.4 × 19.4 5.7 inch)
Weight(without HDD): ≤16kg (35.3lb)
