Video And Audio
IP Video Input: 8-ch,Up to 12 MP resolution
HDMI Output: 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
VGA Output: HDMI,VGA
CVBS Output: 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
Incoming Bandwidth: 80 Mbps,256 Mbps
Audio Output: 1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio: 1-ch, RCA (2.0 Vp-p, 1 k Ω)
Decoding
Decoding Format: H.265/ H.265+/H.264/H.264+/MPEG4
Decoding Capability: 2-ch @ 12 MP (20fps) / 4-ch @ 8 MP (25fps) / 8-ch @ 4MP (30fps) / 16-ch @ 1080p (30fps)
Synchronous Playback: 8-ch
Recording Resolution: 12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/ 2CIF/CIF/QCIF
Network
Network Protocol: TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
Remote Connection: 32
Network Interface: 1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
PoE
Interface: N/A
RAID
RAID Type: No
Auxiliary Interface
SATA: 2
Capacity: Up to 8TB capacity for each HDD
USB Interface: Front panel: 1 × USB 2.0; Rear panel: 1 × USB 3.0
Alarm In/Out: 4/1
General
Power Supply: 12 VDC,≤40 W
Consumption: ≤15 W
Working Temperature: -10 °C to 55 °C (14 °F to 131 °F)
Working Humidity: 10 to 90 %
Dimension (W × D × H): 385 × 315× 52 mm (15.2" × 12.4" × 2.0") or 440 × 393 × 75 mm (17.3" × 15.5" × 3.0") ≤ 1 kg (2.2 lb) or ≤ 5 kg (11 lb)
