Systeem
Besturingssysteem: Linux
ROM: 4 GB
RAM: 512 MB
Processor: Ingebedde processor met hoge prestaties
Videoparameters
Hoofdstream: 4MP (2688x1520P), 2MP (1920x1080P), 1MP (1280x720P)
Substream: 2MP (1920x1080P), 1MP (1280x720P), 0.3MP (640x480P)
Gezichtsveld (FOV): Horizontaal: 150°; Verticaal: 75°
WDR (Wide Dynamic Range): Ondersteund, 120 dB
Aanvullend licht: IR-licht, tot 3 m
Videocompressiestandaard: H.264; H.265; MJPEG
Audioparameters
Audio-ingang: 1 ingebouwde omnidirectionele microfoon
Audiocompressiestandaard: G.711u, G.711a, Opus, AAC-LD, AAC-LC, G.726, G.722.1, G.729
Audio-uitgang: 1 ingebouwde luidspreker
Audiocompressiesnelheid: 8~64 Kbps
Audiokwaliteit: Onderdrukking van ruis en echo
Volumeregeling: Instelbaar
Audioprestaties: 50 cm 80 dB (Maximaal: 50 cm 83 dB)
Audiosamplefrequentie: 16 kHz, 8 kHz
Capaciteit
Gebruikerscapaciteit: 2000
Gezichtsherkenning: /
Kaartcapaciteit: 10.000
Netwerkparameters
Netwerkprotocol: TCP/IP, RTSP, IPv6, ONVIF
Wi-Fi: 2.4G
Bluetooth: Ondersteund
3G/4G: /
Wi-Fi-protocol: IEEE802.11b, IEEE802.11g, IEEE802.11n, IEEE802.11ax
Wi-Fi-type: WiFi 6
Authenticatie
Authenticatiemethoden: Kaart, Bluetooth, Hik-Connect, binnenstation
Kaarttype: Mifare 1
Kaartleesfrequentie: 13.56 MHz
Kaartleesafstand: M1-kaart: 2 tot 2,5 cm
Toepassing
Mobiele app: Hik-Connect
Bewegingsdetectie: Ondersteund
Terugspelen: Ondersteund
Liftoproep: Ondersteund
Slimme functies
Geluidsclassificatie: Detectie van schreeuwen, glasbreukgeluid, huilgeluid
Aanbevolen detectieafstand: 3 m
Apparatuurinterfaces
Alarmingang: 4 (inclusief uitgangsknop en deurcontactingang)
Netwerkinterface: 1 RJ-45, 10/100 Mbps zelfadaptief
Sabotage: 1
Uitgangsknop: 1
RS-485: 1
USB: /
Wiegand: /
TF-kaart: Ondersteund, tot 128 GB
Alarmuitgang: /
Slotbediening: 2 relais, Max. 30 VDC 2 A
Deurcontactingang: 1
Ondersteund TF-formaat: FAT32, exFAT
Algemeen
Knop: 1 fysieke knop
Installatie: Opbouwmontage
Indicatoren: 3
Gewicht:
Zonder verpakking: 273 g (0.61 lb)
Met verpakking: 431 g (0.95 lb)
Beschermingsniveau: IP65
Werktemperatuur: -40 °C tot 60 °C (-40 °F tot 140 °F)
Werkvochtigheid: 10% tot 90% (niet-condenserend)
Afmetingen (B × H × D): 164 mm × 69 mm × 24.7 mm (6.46" × 2.72" × 0.97")
Batterij: /
Toepassingsomgeving: Buiten
Stroomverbruik: < 10 W
Stroomvoorziening: 12 VDC, 1.2 A, IEEE 802.3 at, standaard PoE
Talen
Ondersteunde talen: Engels, Arabisch, Europees Frans, Russisch, Europees Spaans, Latijns-Amerikaans Spaans, Italiaans, Duits, Pools, Turks, Portugees, Braziliaans Portugees, Oezbeeks, Kazachs, Tsjechisch, Hongaars, Nederlands, Roemeens, Bulgaars, Oekraïens, Kroatisch, Servisch, Grieks, Litouws, Ests, Lets, Noors, Deens, Sloveens, Slowaaks, Hebreeuws, Zweeds, Fins, Mongools, Vietnamees, Traditioneel Chinees (Taiwan), Latijns-Amerikaans Spaans
Materiaal
Materiaal voor- en achterzijde: Kunststof
Kijkvensterpaneel: Glas
Stroomuitgang: Max. 12 VDC, 1 A
