Specificaties
Bestelcode
CHQ-SIM
Werkspanning
17 – 41 VDC
Ruststroom / Alarmstroom
150 μA (bij 41 V) maximaal
Open circuit
>100 kΩ
Normale toestand
10 kΩ (EOL weerstand meegeleverd)
Ingangsactivatie
470 Ω (EOL weerstand meegeleverd)
Kortsluiting
50 Ω
Bedrijfstemperatuur
-10 °C tot +50 °C
Opslagtemperatuur
-20 °C tot +60 °C
Maximale luchtvochtigheid
95% RH, niet-condenserend (bij 40 °C)
Kleur / Behuizingsmateriaal
Ivoor / ACS
Gewicht / Afmetingen
25gr. / L 65 mm x B 42 mm x D 15 mm
Goedkeuringen
LPCB, VdS (G210112)
